Product Overview
14 2CDC508198D0211 Rev. A | AC/S 1.x.1
3 Product overview
3.1 Product overview
The devices are modular DIN rail component (MDRC) in the pro M design. The module width of the
devices is 4 space units. The devices are designed for installation in distribution boards on 35 mm
mounting rails.
The devices are powered by the bus and require an additional supply voltage, either 24 V AC/DC or Power
over Ethernet (PoE).
The device connects to the ABB i-bus
®
KNX via the front bus connection terminal.
The software application Engineering Tool Software (ETS) is used for physical address assignment and for
setting the parameters.
The device is ready for operation after connecting the bus voltage and the supply voltage.
Abbreviation Description
A Application
C Controller
/S MDRC
X 1 = Application
X 1 = KNX
2 = KNX + BACnet
X X = Version number (x = 1, 2 etc.)
Table 3: Product name description
3.2 Ordering details
Description MB Type Order No. Packaging
unit [pcs.]
Weight
1 pc.
[g]
Application Controller, Basic 4 AC/S 1.1.1 2CDG110205R0011 1 192
Application Controller, BACnet 4 AC/S 1.2.1 2CDG110206R0011 1 192
Table 4: Ordering details
