ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 407
7.13.4 Group objects
Object function
Name (can be
changed separately)
Data point
type (DPT)
Length
Flags
C
R
W
T
U
I
Output: Operating type
Heating/cooling
changeover
1.100
1 bit
x
x
x
Output: Heating
Heating/cooling
changeover
1.001
1 bit
x
x
x
Output: Cooling Heating/cooling
changeover
1.001 1 bit x x x
Object function Name (can be changed separately) Data type Flags
Output: Operating type
Heating/cooling changeover
1 bit
DPT 1.100
C, R, T
Outputs the active operating type. The value is sent on every change and then repeated every 30 minutes. The cycle time
cannot be changed.
Telegram value: 0 = Cooling
1 = Heating
Output: Heating Heating/cooling changeover 1 bit
DPT 1.001
C, R, T
Outputs the state of the heating operating type. The value is sent on every change and then repeated every 30 minutes. The
cycle time cannot be changed.
Telegram value: 0 = Off
1 = On
Output: Cooling Heating/cooling changeover 1 bit
DPT 1.001
C, R, T
Outputs the state of the heating operating type. The value is sent on every change and then repeated every 30 minutes. The
cycle time cannot be changed.
Telegram value: 0 = Off
1 = On
