ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 177
7.5.4 Group objects
The ASM can only ever transmit/receive one value and therefore has only one group object. Depending on
the template selected, this is an input, output or input/output.
The data point type is also dependent on the parameterization of the ASM.
Object function
Name (can be changed
separately)
Data point type (DPT)
Length
Flags
C
R
W
T
U
I
Input: Value Value Configuration-dependent Configuration-
dependent
x x x
In-/Output: Value Value Configuration-dependent Configuration-
dependent
x x x x
Output: Value
Value
Configuration-dependent
Configuration-
dependent
x
x
x
Object function Name (can be changed separately) Data type Flags
Input: Value
Value
Configuration-
dependent
C, W, T
The module has an input group object if the KNX to WebUI, KNX to BACnet, KNX to ASM output socket template or the Freely
configurable template is selected with the KNX: Input parameter.
Input for the KNX value for output on the parameterized interfaces.
Telegram value: Configuration-dependent
In-/Output: Value
Value
Configuration-
dependent
C, R, W, T
The module has an input/output group object if the
WebUI to KNX with update
,
BACnet to KNX with update
template or the
Freely configurable template is selected with the KNX: Input + output parameter.
Input for the KNX value for output on the parameterized interfaces. Updated values from other interfaces are output again via
this group object.
Telegram value:
Configuration-dependent
Output: Value
Value
Configuration-
dependent
C, R, T
The module has an output group object if the WebUI to KNX, BACnet to KNX template or the Freely configurable template is
selected with the KNX: Output parameter.
The current value from the parameterized interfaces is output via this group object.
Telegram value:
Configuration-dependent
