ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Parameters
270 2CDC508198D0211 Rev. A | AC/S 1.x.1
7.9.4 Group objects
Object function
Name (can be
changed
separately)
Data point type
(DPT)
Length
Flags
C
R
W
T
U
I
Input: Valve control value
Heating distribution
circuit
5.001
1 byte
x
x
x
Input: Supply temperature
Heating distribution
circuit
9.001
2 bytes
x
x
x
Input: Return temperature Heating distribution
circuit
9.001 2 bytes x x x
Output: Supply setpoint temperature Heating distribution
circuit
9.001 2 bytes x x x
Input: Pump A relay status
Heating distribution
circuit
1.001
1 bit
x
x
x
In-/Output: Valve override disable/enable
Heating distribution
circuit
1.003
1 bit
x
x
x
x
In-/Output: Valve override control value Heating distribution
circuit
5.001 1 byte x x x x
Input: Status Valve purge Heating distribution
circuit
1.011 1 bit x x x
Input: Pump A repair switch status
Heating distribution
circuit
1.011
1 bit
x
x
x
Input: Pump A fault
Heating distribution
circuit
1.011
1 bit
x
x
x
Input: Pump A operating status (Off/On) Heating distribution
circuit
1.011 1 bit x x x
In-/Output: Pump A override disable/enable Heating distribution
circuit
1.003 1 bit x x x x
In-/Output: Pump A override value
Heating distribution
circuit
1.001
1 bit
x
x
x
x
Input: Pump B fault
Heating distribution
circuit
1.011
1 bit
x
x
x
In-/Output: Pump B override disable/enable Heating distribution
circuit
1.003 1 bit x x x x
In-/Output: Pump B override value Heating distribution
circuit
1.001 1 bit x x x x
Input: Pump B repair switch status
Heating distribution
circuit
1.011
1 bit
x
x
x
Input: Pump B operating status (Off/On)
Heating distribution
circuit
1.011
1 bit
x
x
x
Input: Pump B relay status Heating distribution
circuit
1.001 1 bit x x x
Output: Control On/Off Heating distribution
circuit
1.001 1 bit x x x
