ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Product Overview
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 19
3.3.4 Technical data
3.3.4.1 General technical data
Supply Bus voltage 21…32 V DC
Current consumption, bus < 12 mA
Power loss, bus Maximum 250 mW
Power loss, device
Maximum 3 W
Supply voltage U
s
24 V AC/DC (+20 % / -15 %) or
PoE (IEEE 802.3af class 2)
Current consumption, supply voltage
90 mA typical
120 mA peak current
KNX connection 0.25 W
KNX current consumption
< 10 mA
Connections KNX Via bus connection terminal
Supply voltage Via screw terminals
0.2…2.5 mm² fine-wire
0.2…4 mm² solid
LAN
RJ45 connector for 10/100BaseT
IEEE 802.3 networks, autosensing
Degree of protection and
protection class
Degree of protection IP 20 according to EN 60529
Protection class II according to EN 61140
Isolation category Overvoltage category III according to EN 60664-1
Pollution degree
II according to EN 60664-1
SELV KNX safety extra low voltage SELV 30 V DC
Temperature range Operation -5...+45 °C
Transport
-25...+70 °C
Storage -25...+55 °C
Ambient conditions Maximum air humidity 93 %, no condensation allowed
Atmospheric pressure
Atmosphere up to 2,000 m
Design
Modular DIN rail component (MDRC)
Modular installation device
Design pro M
Housing/color Plastic, halogen free, gray
Dimensions
Dimensions
90 x 70 x 64 mm (H x W x D)
Mounting width in space units 4x 17.5 mm modules
Mounting depth 68 mm
Mounting
35 mm mounting rail
According to EN 60715
Mounting position Any
Weight 0.192 kg
Fire classification
Flammability V-0 as per UL94
Approvals
KNX certification
According to EN 50090-1, -2
Certification According to EN 60669
CE marking In accordance with the EMC and Low Voltage
Directives
Table 6: Technical data AC/S 1.1.1
