ABB i-bus KNX AC/S 1.x.1 Series User Manual

ABB i-bus
®
KNX
Operation
AC/S 1.x.1 | 2CDC508198D0211 Rev. A 475
9.2.2 Building dashboard
The ASMs and containers are displayed in the same layout as in ETS DCA.
All ASMs for which the user logged in does not have rights are hidden, see chapter 7.3.3, Web user
interface. Any containers that are empty as a result are also hidden.
9.2.3 Navigation menu
The navigation menu shows the structure of the dashboard based on the containers created in ETS. The
navigation menu is generated automatically.
If you select a container, the dashboard scrolls to this point. If you scroll in the dashboard, the actual
position in the navigation menu is displayed.
Hide the navigation menu by clicking the button on the left of the screen.
9.2.4 ASM detailed view
Open the detailed view of the ASM by clicking the ASM's tile. The ASM detailed views are explained in
chapter 7 in the descriptions of the individual ASMs.
Several users can be logged in at the same time and make changes in the ASM detailed views. These
changes are then immediately visible to the other users. The latest change is always applied. There is no
user priority.
After device start, all initial values and restored values and states are marked with the symbol. The
symbol is only hidden once a valid value has been received.
