6 Reference information
6.7. Standard toolkit
3HAC022032-001 Revision: E264
© Copyright 2004-2008 ABB. All rights reserved.
6.7. Standard toolkit
General
All service (repairs, maintenance and installation) procedures contain lists of tools required
to perform the specified activity.
All special tools required are listed directly in the procedures while all the tools that are
considered standard are gathered in the Standard toolkit and defined in the table below.
This way, the tools required are the sum of the Standard Toolkit and any tools listed in the
instruction.
Contents, standard toolkit
Contents, standard toolkit
Qty Tool Rem.
1 Ring-open-end spanner 8-19 mm
1 Socket head cap 5-17 mm
1 Torx socket no: 20-60
1 Box spanner set
1 Torque wrench 10-100 Nm
1 Torque wrench 75-400 Nm
1 Ratchet head for torque wrench 1/2
2 Hexagon-headed screw M10x100
1 Socket head cap no: 14, socket 40 mm bit L 100 mm
1 Socket head cap no: 14, socket 40 mm bit L 20 mm To be shortened to 12 mm
1 Socket head cap no: 6, socket 40 mm bit L 145 mm
1 Socket head cap no: 6, socket 40 mm bit L 220 mm
Qty Tool
1 Ring-open-end spanner 8-19 mm
1 Socket head cap 2.5-17 mm
1 Torx socket no: 20-60
1 Torque wrench 10-100 Nm
1 Torque wrench 8-100 Nm
1 Small screwdriver
1 Plastic mallet
1 Ratchet head for torque wrench 1/2
1 KM nut (KM7)
1 KM socket (KM10) (6369901-480)
1 Socket head cap no: 5, socket 1/2" bit L 20 mm
1 Socket head cap no: 6, socket 1/2" bit L 20 mm
1 Socket head cap no: 8, socket 1/2" bit L 20 mm
1 Small cutting plier
Continues on next page
