7 Part list
7.5. Position switch, axis 1
3HAC022032-001 Revision: E290
© Copyright 2004-2008 ABB. All rights reserved.
7.5. Position switch, axis 1
Part list, position switch
See the Foldout 8 for location of parts.
Item Qty Name Art.no. Note
1 Pos. switch ax 1, 1 sw 3HAC 12042-1 Option 25-2 Standard,
complete set
1 Pos. switch ax 1, 1 sw 3HAC 12042-2 Option 25-2 Foundry,
complete set
1 Pos. switch ax 1, 2 sw 3HAC 12054-1 Option 25-4 Standard,
complete set
1 Pos. switch ax 1, 2 sw 3HAC 12054-2 Option 25-4 Foundry,
complete set
1 Pos. switch ax 1, 3 sw 3HAC 12071-1 Option 25-3 Standard,
complete set
1 Pos. switch ax 1, 3 sw 3HAC 12071-2 Option 25-3 Foundry,
complete set
1 Pos. switch cable 3HAC 7997-1 7 m
1 Pos. switch cable 3HAC 7997-2 15 m
1 Pos. switch cable 3HAC 7997-3 22 m
1 Pos. switch cable 3HAC 7997-4 30 m
1 1 Position switch 1 3HAC 8039-1 ax1 pos.sw. (one) option
1 1 Position switch 1-2 3HAC 8040-1 ax1 pos.sw. (two) option
1 1 Position switch 1-3 3HAC 8041-1 ax1 pos.sw. (three) option
2 1 Segment Foundry 3HAC 6474-1 ax1 pos.sw. (one, two,
three)
3 3 Cam, blank 3HAC 4476-1 ax1 pos.sw. (one)
3 5 Cam, blank 3HAC 4476-1 ax1 pos.sw. (two)
3 7 Cam, blank 3HAC 4476-1 ax1 pos.sw. (three)
4 1 Bracket Foundry 3HAC 6558-1 ax1 pos.sw. (one, two,
three)
5 4 Distance bolt 2125 2052-216 2 1914-04 M6x55
protection (foundry)
5 3 Torx pan head roll. screw 9ADA 629-56 Steel 8-A2F, M4x20,
protection (foundry)
6 2 Hex socket head cap screw 9ADA 183-6 Steel 8.8-A2F. M4x20
ax1possw(one)
6 6 Hex socket head cap screw 9ADA 183-6 Steel 8.8-A2F. M4x20
ax1possw(two)
6 4 Hex socket head cap screw 9ADA 183-6 Steel 8.8-A2F. M4x20
ax1possw(three)
7 4 Shims-sheet 3HAB 7478-1 ax1possw(one)
7 8 Shims-sheet 3HAB 7478-1 ax1possw(two)
7 12 Shims-sheet 3HAB 7478-1 ax1possw(three)
9 6 Torx pan head roll. screw 9ADA 618-54 Steel 8.8-A2F, M6x10
ax1possw(one)
Continues on next page
