1 Safety
1.2.3.7. Work inside the manipulator's working range
3HAC022032-001 Revision: E28
© Copyright 2004-2008 ABB. All rights reserved.
1.2.3.7. Work inside the manipulator's working range
If work must be carried out within the robot’s work envelope, the following points must be
observed:
• The operating mode selector on the controller must be in the manual mode position to
render the enabling device operative and to block operation from a computer link or
remote control panel.
• The robot’s speed is limited to max. 250 mm/s when the operating mode selector is in
position "manual mode with reduced speed". This should be the normal position when
entering the working space. The position "manual mode with full speed (100%)" may
only be used by trained personnel who are aware of the risks that this entails.
• Pay attention to the rotating axes of the manipulator! Keep a distance to the axes in
order not to get entangled with hair or clothing. Also be aware of any danger that may
be caused by rotating tools or other devices mounted on the manipulator or inside the
cell.
• Test the motor brake on each axis, according to section Brake testing on page 25.
