ABB IRB 4400 - 45 User Manual

3 Maintenance
3.2.2. Maintenance schedule
89 3HAC022032-001 Revision: E
© Copyright 2004-2008 ABB. All rights reserved.
3.2.2. Maintenance schedule
General
The robot must be maintained regularly to ensure proper function. The maintenance activities
and intervals are specified in the table below.
Non-predictable situations also give rise to inspections of the robot. Any damages must be
attended to immediately!
The inspection intervals do not specify the life of each component.
Activities and intervals
The table below specifies the required maintenance activities and intervals.
1. The battery is used as a back-up when the robot system is switched off. Therefore, the
life of a lithium battery depends on how frequently the power to the system is switched
off and also if the environment temperature is higher than recommended operating
temperature. The life varies from 12 - 36 mths, depending on current conditions. An
alert is given on the TPU or the FlexPendant when the battery is nearly discharged and
it must then be replaced within a month.
2. The gearboxes are lubricated for life, which corresponds to 40,000 hours of operation
if the robot is operating with an ambient temperature of less than 40° C. If the
temperature is higher, the oil should be changed!
3. Must be replaced if bent!
Maintenance
activity
Equipment Interval Detailed in section
Replacement Battery pack,
measuring system
12-36 mths
1)
Replacement of battery pack,
measuring system on page 94
Replacement Signal cabling, upper
arm (option 042)
12,000 hrs Replacement of signal cabling,
upper arm (option 042) on page
150
Inspection Mechanical stop,
axis 1
Regularly
3)
Inspection of mechanical stop, axis
1 on page 91
Change Oil, gearbox axis 4 12,000 hrs
2)
Oil change, gearbox axis 4 on page
102
Change Oil, gearbox axes 5
and 6
12,000 hrs
2)
• Oil change, gearbox axis 5
and 6 (all robot versions
except IRB 4400/L10) on
page 105
• Oil change, gearbox axis 5
and 6 (IRB 4400/L10 only)
on page 108
Continues on next page
