ABB XIO-04 User Manual

XIO USER MANUAL | 2106424MNAB | 13
Table 1-1: XIO models
Model
Description
Use
XIO-08
4 Ethernet ports, 8 COM ports,
1 TFIO I
2
C bus interface
Dimensions:
3.90
x 3.96 x 4.375 inches (9.91 x 10.06 x 11.11 cm)
Extends both serial and I/O
capacity
XIO-04
4 Ethernet ports, 4 COM ports
1 TFIO I
2
C bus interface
Dimensions:
3.90
x 3.96 x 4.375 inches (9.91 x 10.06 x 11.11 cm)
Extends both serial and I/O
capacity
XIO-00
4 Ethernet ports,
1
TFIO I
2
C bus interface
Dimension
s (This model is narrower since no COM ports are
supported
):
2.04
x 3.96 x 4.375 inches (5.18 x 10.06 x 11.11 cm)
Extends I/O capacity only
IMPORTANT NOTE:
For general specifications, refer to the Data sheet on the XIO Product page.
2 Physical Description
2.1 XIO Housing
A DIN rail mountable plastic housing packages the XIO electronic boards and components.
IMPORTANT NOTE:
The XIO must be installed on an interior wall, or in an enclosure that meets
the environmental ratings
for the location. See section 2.1.1 Enclosures for information about ABB
enclosures
. See section 3.1.1 Enclosure requirements for information about third-party enclosures.
The housing is an interlocked top cover and a base. The following figures illustrate the XIO components
and interfaces (ports). The XIO-08 is used for the illustrations.

ABB XIO-04 Specifications

General

Brand	ABB
Model	XIO-04
Category	Control Unit
Language	English
