XIO USER MANUAL | 2106424MNAB | 191
– When both the RMC and XIOs are in switched mode, the RMC and the XIOs need unique IP addresses
with the same subnet as the single network segment resulting from this mode.
– When the RMC is not in 2-port switch mode, the RMC requires two IP addresses for each of its
Ethernet Interfaces. One for the connection upstream to the local network switch or to the corporate
network. The other for the connection to the XIOs. In this case, the RMC IP address must have the
same subnet as the network it connects to for communication with the XIO.
– When XIOs are not in 4-port switch mode, the XIO IP address configuration depends on how the
interfaces are configured and what network segment is used to connect both the RMC and the XIO.
Unless routers are installed in the field network, traffic between different subnets is not possible. Plan
your field network topology carefully.
Table 9-5: Required connections for XIO – RMC communication
Client app
(RMC)
Server app (XIO)
Connection end points
Network Config
XIO Interface
XIO [Read] Server
RMC IP to XIO IP/Read TCP
port
Both end points MUST
be on same network.
XIO Interface
XIO Write Server
RMC IP to XIO IP/Write TCP
port
Both end points MUST
be on same network.
Communication
Application Instance
Ethernet-Serial
Passthrough instance
RMC IP to XIO IP/E-S Instance
TCP port
Both end points MUST
be on same network.
9.5 Enterprise and industrial (3-network) support
The 4 Ethernet interfaces on the XIO can support separate networks in two sets: The Enterprise Network
ports (port A1 and port A2) and Industrial Network ports (port B1 and port B2). Each of these sets can be
configured independently of the other to provide additional connection and topology options in the field.
IMPORTANT NOTE:
Separate configuration options for these ports become available only when
the XIO 4
-port switch mode is disabled. Configuring an XIO for 3 Network support requires 3
separate su
bnets. The IP address for each supported interface must have the correct subnet.
The Enterprise port set (A-Networks) supports both 1-Network and 2-Network modes. The Industrial port
set (B-Networks) supports only 2-Network mode. For this scenario, the Enterprise Network set is left on
1-Network mode.
Tab le 9-6
summarizes the configuration options for this scenario. The Enterprise Network ports can be
used for device management connections (connections supporting remote or local host access) and the
industrial ports can be used for application and measurement data traffic (supporting device-to-device
communication flows). This scenario supports complex applications with several XIOs and where there is
need to isolate XIOs in separate subnets or domains within in the field. Consult with ABB Technical
Support for more details.
Table 9-6: Enterprise and industrial networks - configuration
Ports: Mode
Ethernet
interface
configuration
Interface
Number of
Networks
Number of required IP
addresses
Enterprise ports:
1 Network
1: One for both
Enterprise ports
A1+A2
1
One per interface:
(A1+A2)
Industrial ports:
2 Networks
2: One for each
Industrial port
B1, B2
2
One per port:
(B1 I P, B2 IP)
