For general purpose nonhazardous locations, the XIO must be installed in an enclosure that complies with
the following specifications:
– For general purpose locations, the enclosure must protect the XIO against shock and impact.
For hazardous locations, the XIO must be installed in an enclosure that complies with the following
specifications:
– For Class I, Division 2, the enclosure must be rated at least Type 3R, according to the environment.
– Class I, Zone 2 requires an enclosure that meets IP54 rating and according to IEC 60529 and IEC
60079-0.
Verify that customer-supplied enclosures meet these requirements.
3.1.2 Location requirements
The installation location should:
– Allow access to the enclosure, XIO, power sources, cables and connections
– Be at a distance that does not exceed the maximum or recommended field wiring lengths for
connections to peripherals or external equipment. Field wiring requirements depend on the type of
connection. See section 3.1.4
.
3.1.3 Mounting requirements
Mounting surfaces or walls require enough strength to support the hanging weight of the enclosure, and
associated equipment to meet the requirements of IEC715.
3.1.4 Install antenna (for wireless functionality)
Wireless support is optional on the XIO. If your device has a wireless interface connector, make sure to
obtain the antenna required to enable communication.
IMPORTANT NOTE:
The Wi-Fi Kit (part number 2106123) is required for antenna installation.
See
Additional information.
3.2 Wiring requirements
Field wiring must meet the following requirements:
– All wiring connections and the screw terminals for power support 14 – 24 AWG and communications
support 16 - 24 AWG. Select the wire gauge according to the voltage and current requirements of the
circuitry. The gauge differs for each application.
– Follow local electrical codes to select the appropriate wire gauge and type based on the load current,
voltage, signal type, and indoor or outdoor environment.
NOTICE
– Equipment damage.
Field installation cable and conductors must be rated greater than
70
°C (158 °F) when installed in an ambient temperature of 60 °C (140 °F).
3.3 Unpack and inspect
The XIO and additional parts ship in a specially designed shipping carton with a Quick Start Guide, Safety
and Compliance notice, and packing list.
IMPORTANT NOTE
: If there is any damage to the shipping carton, keep it and the packing
materials until the conten
ts are inspected and found to be free of damage.
