12. Card Cage
12.3 HD- SDI board + link decryptor
Functionality
Image 12-3
HD-SDI + Link Decryptor
• Converts all HD/SDI video formats to ICP c ompliant pixel mapping
• Contains 7 F ull-HD test patterns (e.g. Co lor Bars, H-Ramp, Moiré, ...)
• Decryption of Cinelink-2 enc rypted content
• Permanent Sec urity monitoring (with battery back-up) : intrusion detection; voltage m onitoring; temperature mo nitoring; se curity
switches; build in self test; ...
• Handles communication with content servers.
• Contains a real time clock (GMT/UTC time); a Certificate and a Private Key
• Battery s helf life: 6 m onths
Replace board
To r eplace the board, follow the procedure as described in Replacem ent of a Card Cage board. R em ove the Link decryptor as
described in Replacem ent of the Link Decryptor
Place the link decryptor on the new board and insert the assembly in the Car d Cage.
210
R5905043 DP2K-12C/11CX 19/02/2018
