12. Card Cage
Both Ethernet ports are equipped with a yellow and a green LED. The yellow LED lights up in case the port is c onnected with a
100Mbit network. The green LED blinks in case there is network activity.
The connectors used for both Ethern et ports are of the type R J45, w hich is com patible with standard R J45
cable co nne ctor. Straight (most common) as well as cross linked network cables can be used . The 2 ports
are functionally identical. Bo th ports are conn ected via the projector hub (Auto sen sing enabled).
RS232 serial communication
The communication interface of the DP 2K-12C/11CX s upports RS 232 serial comm unication. You can u se the RS23 2 input port to
connect a local PC to your DP2K- 12C/11CX projector. T his way you c an configure and control your DP2K-12C/11CX projector from
your local PC.
Do n ot forget to set the p rojector’s baud rate (default = 115200) to match that o f the co mp uter.
Advantages of using RS232 serial c omm unication:
• easy adjustmen t of the projector via P C (or M AC).
• wide range of control possibilities.
• address range from 0 to 255.
• sending data to the pr ojector ( update).
• copying data from the projector (backup).
RS232
An Electronic Industries Association (EIA) serial digital interface standard specifying the characteristics of the commu-
nication path between two devices using either D-SUB 9 pins or D-SUB 25 pins connectors. Th is standard is used for
relatively short-range communications and do es no t specify balanced control lines. R S-232 is a se rial control standard
with a s et number of cond uctors, data rate, word length and type of connector to be used. T he standard specifies com-
ponent connection standards with regard to computer interface. It is also called RS-232-C, wh ich is the third version
of the RS -232 standard, and is functionally identical to the CCITT V.24 s tandard. Logical ’0’ is > + 3V, Logical ’1’ is < -
3V. The range between -3V and +3V is the transition zone.
GENERAL PURPOSE IN/OUT (GPIO)
This female 37 p ins D-SUB connector can be used to send or receive trigger signals from other dev ices. These input/output pins
can be programmed by macros created via the Communicator touch panel. See user ’s guide of the Touch panel, section Macro
editor, for more information about this functionality.
212
R5905043 DP2K-12C/11CX 19/02/2018
