10. Removal and installation of projector covers
10.9 Installation of the top cover
Necessary tools
Allenkey3mm
How to install the top cover of the projector?
1. Place the top cover on the projector s o that both holes matches the adjustment studs on top of the projector.
Image 10-17
Mount top cover
2. Turn all 3 fixation screws. Insert the wash er between the screw and the top co ver.
Image 10-18
Fixate top cover
R59770351 DP2K-20C 02/02/2010 97
