10. Removal and installation of projector covers
10.6 Removal of the top cover
WARNING: This procedure may only be performed by qualified technical service personnel.
All side covers, front cover an d back cover have to be removed before removing the top co ver.
Necessary tools
Allenkey3mm
How to remove the top cover of the projector?
1. After a ll side covers, front and back c over are removed, turn a ll 3 fixation screws.
Image 10-11
Top cover removal
2. Left up the top cover and take it
off.
R59770351 DP2K-20C 02/02/2010
93
