10. Removal and installation of projector covers
10.3 Removal of the front cover
The input co ver an d the lens have to be remo ved before remo ving t he front cover. S ee p rocedures "Removal
of the input cover", page 89, and "Lens remo val", page 49.
Necessary tools
Flat screw driver
How to remove the front cover of the projector
1. Check if the input cover and the lens a re removed.
2. Remov e the rubber dust ring from the lens holder. See the d etail a t the right side of image 10-5.
3. Release the captive screw at the middle bottom of the front cover, using a flat screw drive r.
Image 10-5
Release front cover
4. Remov e the front cover from the projector doing the following:
a) s tanding in front of the projector, pull the upp er right corner (A) of the front cover toward you until the latch releases,
b) pull the lower right corner (B) of the front cover toward you until the latch r eleases,
c) then move the front co ver away from the projector.
A
B
C
Image 10-6
Remove front cover
90 R59770351 DP2K-20C 02/02/2010
