Beckhoff TwinSAFE logic FB User Manual

Function blocks
140 Function blocks for TwinSAFE logic components
3.20.2 Signal description
Table 3-120: FB COMPARE inputs
Name
Permitted type
Data type
Description
CompIn1
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
1st input channel for the comparison (1oo2, 2oo3,
3oo5)
CompIn2
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
2nd input channel for the comparison (1oo2, 2oo3,
3oo5)
CompIn3
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
3rd input channel for the comparison (2oo3, 3oo5)
CompIn4
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
4th input channel for the comparison (3oo5)
CompIn5
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
5th input channel for the comparison (3oo5)
Table 3-121: FB COMPARE outputs
Name
Permitted type
Data type
Description
Error
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Error output (see diagnostic information)
IsValid
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output indicating whether the comparison has a
positive or negative result
(positive=1, negative=0)
CompOut
TwinSAFE-Out
FB-In
Standard-Out
INT16
INT32
UINT16
UINT32
Output channel with the first CompIn input value that
lies within the comparison result
Table 3-122: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-123: Internal identifier of the FB
Type
Description
FB COMPARE
This description applies to BLG 1.0 (internal version number)
