Beckhoff TwinSAFE logic FB User Manual

Function blocks
26 Function blocks for TwinSAFE logic components
3.1.2 Signal description
Table 3-1: FB AND inputs
Name
Permitted type
Data type
Description
AndIn1
TwinSAFE-In
FB-Out
Standard-In
BOOL
1st input channel
AndIn2
TwinSAFE-In
FB-Out
BOOL
2nd input channel
AndIn3
TwinSAFE-In
FB-Out
BOOL
3rd input channel
AndIn4
TwinSAFE-In
FB-Out
BOOL
4th input channel
AndIn5
TwinSAFE-In
FB-Out
BOOL
5th input channel
AndIn6
TwinSAFE-In
FB-Out
BOOL
6th input channel
AndIn7
TwinSAFE-In
FB-Out
BOOL
7th input channel
AndIn8
TwinSAFE-In
FB-Out
BOOL
8th input channel
Table 3-2: FB AND outputs
Name
Permitted type
Data type
Description
AndOut
TwinSAFE-Out
FB-In
Standard-Out
Local-Out
BOOL
Output channel
Table 3-3: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input, e.g. at an EL1904/KL1904
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output, e.g. at an EL2904/KL2904
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
Local-Out
TwinSAFE output at the KL6904 (not available for EL6900)
Table 3-4: Internal identifier of the FB
Type
Description
FB AND
This description applies to BLG 1.0 (internal version number)
