Function blocks
186 Function blocks for TwinSAFE logic components
3.26.7 Diagnostics messages excentric mode
3.26.7.1 Parameter error
In excentric mode the following parameter errors may occur and be reported accordingly.
TDC1UpperLimit <=
AllowedPositionJitter
The TDCUpperLimit (%d) is lower
or equal than the maximum
position jitter (%d)
(TDC1UpperLimit +
2*AllowedPositionJitter)
>= OverrunMax
The value of TDCUpperLimit
(plus twice the maximum position
jitter) (%d) is bigger or equal the
value of OverrunMax (%d)
TDC1Upper
Limit +
2*Allowed
PositionJitter
(OverrunMax +
2*AllowedPositionJitter)
>= BDCLowerLimit
The value of OverrunMax (plus
twice the maximum position jitter)
(%d) is bigger or equal the value
of BDCLowerLimit (%d)
OverrunMax +
2*Allowed
PositionJitter
(BDCLowerLimit +
AllowedPositionJitter)
>= MaxPosition/2
The value of BDCLowerLimit
(plus maximum position jitter)
(%d) is greater or equal the
configured value of 180° (%d)
BDCLower
Limit +
Allowed
PositionJitter
BDCUpperLimit <=
(MaxPosition/2 +
AllowedPositionJitter)
The value of BDCUpperLimit
(%d) is smaller or equal the
configured value of 180° (plus
maximum position jitter) (%d)
MaxPosition/2
+ Allowed
PositionJitter
(BDCUpperLimit +
2*AllowedPositionJitter)
>= TDC1LowerLimit
The value of BDCUpperLimit
(plus twice the maximum position
jitter) (%d) is bigger or equal the
value of TDCLowerLimit (%d)
BDCUpper
Limit +
2*Allowed
PositionJitter
(TDC1LowerLimit +
AllowedPositionJitter) >
MaxPosition
The value of TDCLowerLimit
(plus maximum position jitter)
(%d) is bigger or equal the
configured position of 360° (%d)
TDC1Lower
Limit +
Allowed
PositionJitter
Position > (MaxPosition
+AllowedPositionJitter)
The Position (%d) is bigger than
the maximum position (plus the
maximum position jitter) (%d)
MaxPosition+
Allowed
PositionJitter
