Beckhoff TwinSAFE logic FB User Manual

Function blocks
Function blocks for TwinSAFE logic components 157
3.24 The function block SPEED
3.24.1 Functional description
The FB SPEED is used to store the AnalogIn input and calculate a speed from it, based on the specified
time interval. The input data types INT16, INT32, UINT16 and UINT32 are permitted. The output must be
selected to match the input types. The speed is output in increments per time interval.
The parameter Time Interval is specified in ms
Figure 3-100: Function block SPEED
NOTE
KL6904/EL6900
The function block SPEED is not available in the KL6904 and the EL6900.
