Beckhoff TwinSAFE logic FB User Manual

Function blocks
Function blocks for TwinSAFE logic components 211
3.30.2 Signal description
Table 3-187: FB OR inputs
Name
Permitted
type
Data type
Description
Xor1In1
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR1
Xor2In1
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR1
Xor1In2
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR2
Xor2In2
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR2
Xor1In3
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR3
Xor2In3
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR3
Xor1In4
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR4
Xor2In4
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR4
Xor1In5
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR5
Xor2In5
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR5
Xor1In6
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR6
Xor2In6
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR6
Xor1In7
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR7
Xor2In7
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR7
Xor1In8
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input1 of XOR8
Xor2In8
TwinSAFE-In
FB-Out
TwinSAFE SC
BOOL
Input2 of XOR8
