Function blocks
36 Function blocks for TwinSAFE logic components
3.3.2 Signal description
Table 3-13: FB OPMODE inputs
Name
Permitted type
Data type
Description
Restart
TwinSAFE-In
FB-Out
Standard-In
BOOL
The 0->1->0 signal sequence must be detected on
the restart input, before the safe state of the outputs
can be removed, when starting the FB or when all
outputs are switched to the safe state. No time
monitoring of the restart signal takes place.
OpIn1
TwinSAFE-In
FB-Out
BOOL
1st input channel
OpIn2
TwinSAFE-In
FB-Out
BOOL
2nd input channel
OpIn3
TwinSAFE-In
FB-Out
BOOL
3rd input channel
OpIn4
TwinSAFE-In
FB-Out
BOOL
4th input channel
OpIn5
TwinSAFE-In
FB-Out
BOOL
5th input channel
OpIn6
TwinSAFE-In
FB-Out
BOOL
6th input channel
OpIn7
TwinSAFE-In
FB-Out
BOOL
7th input channel
OpIn8
TwinSAFE-In
FB-Out
BOOL
8th input channel
