Function blocks
158 Function blocks for TwinSAFE logic components
3.24.2 Signal description
Table 3-148: FB Speed inputs
Name
Permitted type
Data type
Description
Position
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
INT16
INT32
UINT16
UINT32
Input channel for speed calculation
Table 3-149: FB Speed outputs
Name
Permitted type
Data type
Description
Error
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Error output (see diagnostic information)
Speed
TwinSAFE-Out
FB-In
Standard-Out
INT16
INT32
UINT16
UINT32
Output with the calculated speed
Table 3-150: FB Speed input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-151: Internal identifier of the FB
Type
Description
FB SPEED
This description applies to BLG 1.0 (internal version number)
3.24.2.1 Diagnostic and state information for the FB Speed
Table 3-152: Diagnostic information
Value
Description
0
No diagnostic information
1
The Speed output has an underflow (is less than the smallest possible value)
2
The Speed output has an overflow (is greater than the largest possible value)
Table 3-153: Diag Message
Text ID
Meaning
Parameter 1
Parameter 2
Parameter 3
0x4088
An underflow has occurred.
FB number
current position
latched position
0x4089
An overflow has occurred.
FB number
current position
latched position
