Function blocks
Function blocks for TwinSAFE logic components 149
3.22.2 Signal description
Table 3-134: FB Counter inputs
Name
Permitted type
Data type
Description
Reset
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
BOOL
Reset input for resetting the counter to Preset
Value
CountUp
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
BOOL
CountUp input for incrementing the internal
counter value by 1
CountDown
TwinSAFE-In
FB-Out
Standard-In
TwinSAFE SC
BOOL
CountDown input for decrementing the internal
counter value by 1
Table 3-135: FB Counter outputs
Name
Permitted type
Data type
Description
Error
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Error output (see diagnostic information)
CounterOut
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output is set when the counter limit is reached
CounterZero
TwinSAFE-Out
FB-In
Standard-Out
BOOL
Output is set when the internal counter value is
0
ActValue
TwinSAFE-Out
FB-In
Standard-Out
INT16
INT32
UINT16
UINT32
Current internal counter value
Table 3-136: Input and output types
Type
Description
TwinSAFE-In
TwinSAFE input of an EL1904/KL1904, e.g.
Standard-In
Standard PLC variable (output in the PLC %Q*)
FB-Out
TwinSAFE FB output
TwinSAFE-Out
TwinSAFE output of an EL2904/KL2904, e.g.
Standard-Out
Standard PLC variable (input in the PLC %I*)
FB-In
TwinSAFE FB input
TwinSAFE SC
Input of a TwinSAFE connection (TwinSAFE SC technology)
Table 3-137: Internal identifier of the FB
Type
Description
FB COUNTER
This description applies to BLG 1.0 (internal version number)
