Beckhoff TwinSAFE logic FB User Manual

Function blocks
90 Function blocks for TwinSAFE logic components
3.8.4.1 Diagnostic and state information for FB MUTING with functional expansion
Table 3-49: Diagnostic information (16-bit value)
Bit
Description
0
Discrepancy error in muting input group 1
1
Discrepancy error in the OSSD input group
2
Discrepancy error in muting input group 2
4
EDM monitoring error EDM1
5
EDM monitoring error EDM2
6
Muting sequence was violated
7
Maximum muting time was exceeded
8
Discrepancy error in muting input group 1 was not yet reset
9
Discrepancy error in OSSD input group was not yet reset
10
Discrepancy error in muting input group 2 was not yet reset
Table 3-50: State information (8-bit value)
Value
Description (see Table 3-48)
0
undefined
1
RUN
2
STOP
3
SAFE
4
ERROR
5
RESET
6
not used
7
not used
8
DELAYOUT
9
MUTING1 (Figure 3-35 number 2-3)
10
MUTING2 (Figure 3-35 number 3-4)
11
MUTING3 (Figure 3-35 number 4-5)
12
MUTING4 (Figure 3-35 number 5-6)
13
MUTING5 (Figure 3-35 number 6-7)
14
MUTING6 (Figure 3-35 number 7-8)
15
MUTING7 (Figure 3-35 number 8-9)
16
MUTING8 (Figure 3-35 number 9-10)
17
MUTING9 (Figure 3-35 number 10-11)
