Chapter 5 Editing Embroidery Data
BES-940BC • BES-1240BC
110
Upper left
Editing
Rotate
Available range of rotation is -359 to 359 degrees.
When the patterns to be repeated are grouped, the whole pattern rotates. When
they are not grouped, each pattern rotates in each hoop.
When the patterns are grouped When the patterns are not grouped
1. Select [Rotate] from View menu or click .
2. Select angle.
If [Free] is selected, specify the angle.
3. Click [OK].
To select angle.
The value can be directly entered.
Click here to increase/decrease
the value.
To Next Page
