Brother BE-0901E PC User Manual

BES-940BC • BES-1240BC
16
Chapter 1 An Introduction of Sewing Machine
Embroidery machine used
9 needle embroidery machine head 12 needle embroidery machine head
(four-head type) (four-head type)
Application Pattern embroidery
Sewing speed Maximum 1000 rpm
450 (V) x 400 (H) mm (border frame area)
Sewing area
430 (V) x 300 (H) mm (tubular square hoop area)
85 (V) x 360 (H) mm (cap frame area)
450 (V) x 460 (H) mm (with every other head control)
Feed system By timing belt and stepping motor drive
Stitch length 0.1 ~ 12.7 mm (minimum pitch: 0.1 mm)
3.5 2DD floppy disk (Tajima format)
Paper tape with 25.4 mm width/8 holes (Tajima, Barudan, Zanks)
Storage medium 3.5 2HD floppy disk (the equivalent to Tajima format)
3.5 2DD floppy disk (Barudan FDR/FMC format)
3.5 2DD floppy disk (ZSK format)
Thread trimming Automatic thread trimmer
Needle thread breakage Needle thread breakage detector
Power supply Single phase 200 V, 50/60 Hz, 1.7kVA
Weight 600 kg 600 kg
(Before assembly) 2750 (W) x 810 (L) x 1665 (H) mm
Dimensions (After setup) 2750 (W) x 1400 (L) x 1665 (H) mm
(Distance between machine heads) 400 mm
Options
Paper tape reader, Embroidery hoops in different sizes, Bobbin winder,
Parts for boring
Fluorescent lamp Option Standard
1. Specifications

Brother BE-0901E PC Specifications

General

Needles	1
Display	LCD
Foot Control	Included
Presser Feet	Embroidery foot
Included Accessories	Embroidery Frames
