Chapter 2 Preparation of Embroidery Machine
BES-940BC • BES-1240BC
44
3. Preparation for Embroidering
Turn off the power switch before starting preparation.
Failure to do so may start the machine unintentionally through an accidental activation of the START switch,
resulting in bodily injuries.
CAUTION
3-1 Upper Threading
BES-940BC
1. Pass the upper thread from the cotton stand through the hole of the thread guide right above
each cotton stand bar from the lower side.
2. Pass the thread through the upper hole of the pretension. Push up the tension disc with your
finger, and place the thread under the disc. Then, pass it through the lower hole.
3. Pass the thread through the upper hole of the 2nd pretension. Push up the tension disc with
your finger, and place the thread under the disc. Then, pass it through the lower hole, and
wind it around the thread breakage pulley twice.
4
3
2
1
5
6
7
8
No.2,5,8
No.1,4,7
Needle Bar No.3,6,9
To Next Page
