BES-940BC • BES-1240BC
137
Chapter 6 Embroidering
Grid
Displays 1 x 1 cm square grids on the background.
1. Select [Grid] from View menu and put the check mark.
Before selecting After selecting
Hoop
Displays the outline of embroidery hoop. The type of embroidery hoop can be
changed in [Load Hoop] of Settings menu.
Embroidering is allowed within the green guide in the hoop.
1. Select [Hoop] from the View menu and put a check mark.
If the hoop is not displayed, carry out the step to read the hoop. For details, refer to [Load Hoop]
( page 174).
Before selecting After selecting
Hoop position fine adjustment
Adjusts the view position of embroidery hoop.
The position can be adjusted in the range of ±20 mm in both the X and Y directions.
1. Select [Hoop position] from the View menu.
The hoop view position is stored in the hoop data. If you reinstall the program, the hoop view
position is initialized because it is overwritten.
