Chapter 7 Operation of Machine
BES-940BC • BES-1240BC
192
1. Operating Procedures
1-1 Power Source
1. Turn the power on to the machine.
2. Reset the emergency stop button.
3. Press the high power switch.
4. The power lamp lights up and the display
window indicates "BES-", and then "940
(BES-1240BC : "1240")".
• An alarm buzzer sounds three times. Then
the needle bar and presser foot move up
and the frame moves up to the reference
point.
The machine enters the waiting state for an
embroidering data selection.
Note) When turning the power off and back it on
again, wait for at least 10 seconds.
1-2 Preparation for Embroidering
• Select embroidering data while the machine is in the waiting state for an embroidering data
selection, and transmit required data by pressing the
icon.
• The READY lamp lights up and the machine is placed in the waiting state.
• Using the jog switches (
), determine a position to start embroidering.
Note) An error code is displayed in the display window if a pattern comes out of the hoop.
• Pressing the START switch starts embroidering.
START
* During embroidering, the speed is indicated in the display window.
• After embroidering is finished, the hoop returns to the start point and the machine is placed
in the stand-by state.
Emergency stop button Power switch
