BES-940BC • BES-1240BC
146
Chapter 6 Embroidering
Viewing Machine Information
Detail specification of the machine can be displayed.
1. Select [Machine Information] from Machine menu.
2. Click [OK] after checking the information.
Design Information
Detail specification of the embroidery data can be checked.
Pattern name File name and path of embroidery data
No. of stitches The number of stitches in embroidery data
No. of colors The number of colors used in embroidery data
Mask Size Size of masking
Start of Embroidering Coordinates of embroidering start position
End of Embroidering Coordinates of embroidering end position
1. Select [Design Information] from Help menu or click .
2. After checking, click [OK].
Setting Window Display
Specifies the window that displays machine condition if multiple machines are
connected simultaneously.
There are two types of window display as follows:
Cascade Windows are slightly offset.
Tile Windows are tiled.
To Next Page
