BES-940BC • BES-1240BC
169
Chapter 6 Embroidering
Default Settings
Resets changes of the machine setting to the default.
Items for setting and initialization are as follows:
Speed Range
Automatically selects the value suitable for the hoop type.
Head Operation Suspend Cancels the head operation which is not set for rest on
the machine.
Hoop Feed Position Returns to the machine home position.
Embroidering Area Sets the size each for the selected hoop.
Thread Trimming Inching motion Yes
Thread removal feed length 15 mm (0.6 inch)
Thread remaining amount 5
Boring Boring No
Data shift No
Thread Breakage Sensor All sensors are on.
Sensitivity 10
Automatic Step Back 0
Thread Breakage Not affected by the thread breakage sensor sensitivity
Sensor Sensitivity
Automatic Feed Hoop No
Return to the start point Yes
Mending Automatically rest breakage error No
Automatically reset the rotary hook thread entanglement error
No
Raise the presser foot when resetting the thread trimming error
Yes
Stop the machine at the mending end position Yes
Stitches before mending 1 stitch
Trim during stop in mending setting No
Conduct lock stitch when trimming thread No
Adjustment 0.0 mm for X direction
0.0 mm for Y direction
Speeding up startup of the main shaft No
Hoop feed during temporary stop for color change No
Reducing speed in a small pitch No
Thin material or thick material 110 degrees
Area Trace "Eight-sided" is selected.
