3-9
Confidential
6 OVERVIEW OF GEARS
ADF drive gear
1 LEG777 Separation roller gear (external)
2 LEG779 Document feed roller 1 gear
3 LEG780 Idle gear 63
4 LEG781 Document feed roller 2 gears
(3_009)

