4-17
Confidential
3 IF YOU REPLACE THE DOCUMENT SCANNER UNIT OR CIS UNIT
<Operations>
3.1 Set the CIS Type (Maintenance mode 59)
3.2 Acquire Black and White Level Data (Maintenance mode 55)
3.3 Check Scanning
<Requirements>
(1) USB cable: 1 piece
(2) Create a temporary folder in the PC's C drive (Windows
®
XP or later).
(3) Download utility (FILEDG32.EXE)
Make a copy of the download utility in the temporary folder in the C drive.
(4) Maintenance driver (MaintenanceDriver.zip)
Make a copy of the maintenance driver in the temporary folder in the C drive. Extract
the copied file and install it. Refer to "APPENDIX 3. INSTALLING THE
MAINTENANCE DRIVER" for details on the installation.
(5) Color test chart CTC-001
3.1 Set the CIS Type (Maintenance mode 59)
Refer to Chapter 5 "1.4.18 Checking of CIS Travel and Specifying of CIS Type
(Maintenance mode 59)" for details on the execution.
After execution, install the firmware in Section 1.3 when "PLS UPDATE PROG" is
displayed on the LCD.
3.2 Acquire Black and White Level Data (Maintenance mode 55)
Refer to Chapter 5 "1.4.15 Acquisition of White/Black Level Data and CIS Scanner Area
Setting (Maintenance mode 55)" for details on the execution.
3.3 Check Scanning
To make a final check after replacement, check a copy of an color test chart.
Refer to "1.14 Check Scanning and Printing" in this chapter on how to copy the color test
chart.
To Next Page
