5-17
Confidential
<Operating Procedure>
(1) Enter [1] and [0] in the initial stage of the maintenance mode.
The machine displays "WSW00" on the LCD.
(2) Enter a double-digit worker switch number to be modified.
The following appears on the LCD.
Selector No. 1 Selector No. 8
WSWXX =0
0 0 0 0 0 0 0
(3) Enter the [ ] or [ ] to move the cursor to the selector position to be modified.
Enter the [1] or [0] to change the setting.
(4) When finished making change, press [SET] or [OK].
This operation saves the newly entered selector values onto the EEPROM and readies
the machine for accepting a worker switch number ("WSW00").
(5) When all switch inputs are finished, press [Stop] or [X] to return the machine to the
initial stage of the maintenance mode.
Note • To cancel the setting and return to the initial stage of the maintenance mode, press
[Stop] or [X].
• If there is a pause of more than one minute after a single-digit number is entered
for double-digit firmware switch numbers, the machine automatically returns to the
initial stage of the maintenance mode.
[2] Printout of Worker Switch Data (Maintenance mode 11)
<Function>
This function prints out the setting items of the worker switches and their contents
specified.
<Operating Procedure>
(1) Enter [1] and [1] in the initial stage of the maintenance mode.
The machine shows "PRINTING" on the LCD and prints out the configuration list as
shown below.
If no recording paper is loaded in the paper tray, printing will be canceled.
(2) Upon completion of printing, the machine returns to the initial stage of the maintenance
mode.
