1.3 List of Maintenance-mode Functions
Shaded maintenance mode functions are available to end users.
* Exclusive to the end user-accessible maintenance mode.
Maintenance
Mode
Function
Reference Section
(Page)
01
EEPROM Parameter Initialization
1.4.1 (5-6)
02
Creating of Head Calibration Data and Writing it into Flash ROM
1.4.2 (5-7)
05
Printout of Scanning Compensation White/Black Level Data
1.4.3 (5-10)
08
ADF Performance Test
1.4.4 (5-13)
09
Printout of Test Pattern
1.4.5 (5-13)
10
Worker Switch (WSW) Setting
1.4.6 (5-15)
11
Printout of Worker Switch (WSW) Data
1.4.6 (5-15)
12
Operational Check of LCD
1.4.7 (5-19)
13
Operational Check of Keys on Control Panel
1.4.8 (5-21)
17 *
EEPROM Dump Transfer
1.4.9 (5-22)
32
Sensor Operational Check
1.4.10 (5-23)
37 *
Printout of Dial Log.
1.4.11 (5-25)
52
Setting of Country/Language
1.4.12 (5-25)
53
Transfer of Received FAX Data and/or Equipment's Log
1.4.13 (5-26)
54
Fine Adjustment of Scanning Position
1.4.14 (5-28)
55
Acquisition of White/Black Level Data and CIS Scanner Area
Setting
1.4.15 (5-29)
57
Cartridge IC Communication Check
1.4.16 (5-30)
58
Updating of Paper Feeding Correction Value
1.4.17 (5-31)
59
Checking of CIS Travel and Specifying of CIS Type
1.4.18 (5-35)
63
Move of the Head/carriage unit to the Adjustment Position
1.4.19 (5-36)
65
Adjustment of the Vertical Print Lines/Software Correction for
Inclination/Corrugation/Ruled Lines
1.4.20 (5-37)
66
Margin Adjustment in Borderless Printing
1.4.21 (5-40)
68
Updating of Head Property Data
1.4.22 (5-43)
69
Traveling Speed Check of Head/carriage unit
1.4.23 (5-44)
74
Customize Code Destinations
1.4.24 (5-45)
75
Moving the Head/carriage unit to the Center
1.4.25 (5-48)
76
Purge Operation
1.4.26 (5-49)
77
Print of the Maintenance Information
1.4.27 (5-52)
78
Adjustment of Touch Panel
1.4.28 (5-54)
80
Display of the Equipment's Log
1.4.29 (5-55)
82
Equipment Error Code Indication
1.4.30 (5-58)
87
Output of Transmission Log to the Telephone Line
1.4.31 (5-58)
88
Assurance Mode Switch Setting (AMS)
1.4.32 (5-59)
91
EEPROM Parameter Initialization
1.4.1 (5-6)
99
Exit from the Maintenance Mode
