4.6 Control Panel Problems
4.6.1 No display on the LCD
4.6.2 LED does not light up
4.6.3 The control panel does not work
4.6.4 Touch panel inoperative (only for models with a touch panel)
Step Cause Solution
1 Panel harness connection failure Reconnect the Panel harness.
2 LCD flat cable connection failure Reconnect the LCD flat cable.
3 Panel PCB defective Replace the Panel PCB. (1-Line LCD model)
4 LCD unit defective Replace the Control panel ASSY and LCD unit.
5 Power cord defective Replace the Power supply PCB ASSY.
(US/CAN)
Replace the Power cord. (Outside US/CAN)
6 Power supply PCB defective Replace the Power supply PCB ASSY.
7 Main PCB defective Replace the Main PCB ASSY.
Step Cause Solution
1 Panel harness connection failure Reconnect the Panel harness.
2 Panel PCB defective Replace the Panel PCB. (1-Line LCD model)
3 Control panel ASSY defective Replace the Control panel ASSY.
4 Power cord defective Replace the Power supply PCB ASSY.
(US/CAN)
Replace the Power cord. (Outside US/CAN)
5 Power supply PCB defective Replace the Power supply PCB ASSY.
6 Main PCB defective Replace the Main PCB ASSY.
Step Cause Solution
1 Panel harness connection failure Reconnect the Panel harness.
2 Rubber key not properly attached Reattach the Rubber key. (1-Line LCD model)
3 Rubber key defective Replace the Rubber key. (1-Line LCD model)
4 Panel PCB defective
Replace the Panel PCB ASSY. (1-Line LCD model)
5 Control panel ASSY defective Replace the Control panel ASSY.
6 Main PCB defective Replace the Main PCB ASSY.
Step Cause Solution
1 Touch panel unadjusted Adjust the Touch panel.
(Refer to Chapter 5, Section 1.4.28)
2 Panel harness connection failure Reconnect the Panel harness.
3 Control panel ASSY defective Replace the Control panel ASSY.
4 Main PCB defective Replace the Main PCB ASSY.
