Canon imagePROGRAF iPF815 User Manual

Sheet printing
Sheets refer to individual sheets of paper.
Insert the sheet between the Platen and the Paper Retainer.
• Enlarged/reduced printing
You can freely adjust the size of originals by enlarging or reducing originals before printing.
(See "Resizing Originals to Match the Paper Size.")
→P.65
(See "Resizing Originals by Entering a Scaling Value.") →P.77
• Free Layout function
Print multiple documents from multiple applications (such as word-processing programs, spreadsheet programs, and so
on) next to each other.
(See "Printing Multiple Originals Next to Each Other.") →P.133
Loading and Printing on Rolls
These are the basic steps for loading and printing on rolls.
Follow these steps to switch to a new roll or a roll of a different type or width before printing.
Note
• The procedure varies depending on the ManageRemainRoll setting in the printer menu and whether or not a
barcode has been printed on the loaded roll. (See "Keeping Track of the Amount of Roll Paper Left.")
→P.639
• Steps 6 and 7 are unnecessary if ManageRemainRoll is On and a barcode has been printed on the roll.
• Step 7 is unnecessary if ManageRemainRoll is Off.
• When Width Detection in the printer menu is Off, after you have selected the type of paper in step 6, you
will need to enter the roll width. (See "Main Menu Settings.") →P.722
• For
details on supported sizes and types of rolls, see Paper Sizes or the Paper Reference Guide. (See "Paper
Sizes.")
→P.620 (See "Types of Paper.") →P.617
• If
you are not using the optional Media Take-up Unit when printing long documents such as banners, spread
a clean cloth or paper on the floor. Use the Stationary Output Stacker to prevent long printed documents from
being soiled by the floor after they are printed. (See "Using the Stationary Output Stacker.")
→P.659
• If
you prefer to wait for the ink to dry after printing and simply eject the document, you can deactivate auto-
matic cutting and cut the paper manually. (See "Specifying the Cutting Method for Rolls.")
→P.642
1. Turn the printer on. (See "Turning the Printer On and Off.")
→P.694
Basic Printing Workflow
> Printing procedure >
iPF815 Loading and Printing on Rolls
1
3

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
