Note
• You
can start Head Cleaning A by holding down the Information button for three seconds or more. (See
"Cleaning the Printhead.")
→P.819
Printer Menu Operations
The printer menu includes a main menu and submenus.
• Main menu operations when no print job is in progress →P.704
• Main menu operations during printing →P.704
• Submenu operations →P.705
Main menu operations when no print job is in progress
Access the main menu by pressing the Menu button on the Control Panel.
Note
• The main menu will not be displayed in the following case even if you press the Menu button.
• An error message is displayed:
Switches to Menu mode after the problem is solved.
The following operations are available from the main menu.
• Paper settings
• Print settings
• Printer settings
• HP-GL/2 settings
• Job management menu operations
For a description of specific items available in the main menu, see "Main Menu Settings."
→P.722
For instructions on selecting and setting main menu items, see "Main Menu Operations." →P.705
Note
• By
default, main menu settings apply to all print jobs. However, for settings that are also available in the
printer driver, the values specified in the printer driver take priority.
Main menu operations during printing
The Menu Durng Prtng and Job Mgmt Menu can be accessed from the Menu Selection screen by pressing the Menu
button on the control panel during printing. Other menus are available after printing is finished.
Note
• The Menu Selection screen will not be displayed in the following case even if you press the Menu button.
• An error message is displayed:
Switches to Menu mode after the problem is solved.
The following operations are available from the main menu during printing.
Menu Durng Prtng
• Printhead cleaning
• Manual adjustment of the paper feed amount
Printer Parts
> Control Panel >
Printer Menu Operations iPF815
9
704

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
