Item Details
Default
Setting
NDS PSer-
ver
Tree Name Specify the name of an NDS tree that has a NetWare print server.
(0–32 characters)
—
Context Name Specify the name of a context that has a NetWare print server.
(0–255 characters)
—
Print Server
Name
Specify the name of a NetWare print server.
(0–64 characters)
—
Print Server
Password
Set a password for the print server.
(0–20 characters)
—
Polling Interval Specify the interval to confirm jobs.
(1–255 seconds)
5
NPrinter Print Server
Name
Specify the name of a NetWare print server.
(0–47 characters)
—
Printer Number Specify the number of the printer connected to the NetWare print
server.
(0–254)
0
7. Click OK to display the Network page.
Specifying the Printer's Frame Type
To enable communication between the printer and computers on your network, specify the Ethernet frame type in your Net-
Ware environment.
Follow the steps below to specify the frame type by using imagePROGRAF Device Setup Utility or the printer Control
Panel.
Note
• You can specify the frame type by using RemoteUI if the printer's IP address is configured.
Important
• Before specifying the frame type, make sure the printer is on and connected to the network.
• For
instructions on installing imagePROGRAF Device Setup Utility, see "Installing imagePROGRAF De-
vice Setup Utility."
→P.403 .
Specifying the Frame Type Using imagePROGRAF Device Setup Utility
1. Start imagePROGRAF Device Setup Utility.
2. In the list of printers, select the printer to configure.
3. Choose Protocol Settings from the Printer menu.
4. In the NetWare Frame Type list, select the frame type.
5. Click ETHERNET II under Frame Type in TCP/IP.
Network Setting
> Network Setting (Windows) >
iPF815 Specifying the Printer's Frame Type
10
785

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
