Canon imagePROGRAF iPF815 User Manual

E Paper Size
Specify the desired Width and Height. You can make your selection from sizes that are compatible with Borderless Print-
ing by selecting Borderless Printing Size. To maintain the aspect ratio of the Width and Height as you resize the paper,
select Fix the Ratio of the Width to Height.
F Add
Enables you to register the custom paper size you have specified or overwrite an existing custom paper size.
G Display Series
You can limit the number of options shown in Page Size, Paper Size, and Paper Size List.
Layout Sheet
The following settings are available on the Layout sheet. For details on settings items, refer to the printer driver help.
A Page Layout
Activate this setting to select a particular page layout.
• Printing Multiple Pages Per Sheet
→P.143
• Printing Posters in Sections →P.150
• Printing Multiple Originals Next to Each Other →P.133
• Using PosterArtist to Compose Originals →P.181
B Set
Click to display one of the following dialog boxes depending on the selection in A Page Layout. In these dialog boxes, you
can specify layout details and which pages to print, as well as other settings.
Windows Software
> Printer Driver >
iPF815 Layout Sheet
4
233

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
