Canon imagePROGRAF iPF815 User Manual

P Sharpen Text
Activate this option to print text more sharply.
K Reduce Print Unevenness
Select this checkbox for two-pass printing to reduce color shading.
This option is displayed if you have selected Plain Paper in Media Type and Office Document in Print Priority.
N Economy Printing
Select this checkbox to reduce the amount of ink consumed during printing. However, the print quality is worse than for
normal printing.
Select this mode if you want to conserve ink when checking drawings, for example. Depending on the Media Type and
Print Quality settings, this mode may not be available.
Paper Information on Printer Dialog Box
On the Paper Information on Printer dialog box, you can obtain information on the paper in the printer and configure
printer driver media type setting.
Note
• To
display the Paper Information on Printer dialog box, on the Main pane, click Get Information by
Media Type.(See "Main Pane
→P.433 ")
A Paper Source
Shows the Paper Source supported by the printer, as well as the type of paper loaded. To update the media type setting in
the printer driver, select the desired Paper Source option and click OK.
Mac OS X Software
> Printer Driver >
iPF815 Paper Information on Printer Dialog Box
5
437

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
