Canon imagePROGRAF iPF815 User Manual

Printing does not start
The Data lamp on the Control Panel does not light up .................................................................................... 863
The printer does not respond even if print jobs are sent ................................................................................. 863
Ink Filling.. is displayed ................................................................................................................................... 863
The display screen indicates Agitating ............................................................................................................ 864
The Data lamp on the Control Panel does not light up
Cause Corrective Action
The printer is not on. Make sure the power cord is securely plugged in, all the way. Press the Power but-
ton to turn on the printer.
The target printer was not selec-
ted when printing. (The printer is
in Sleep mode.)
In Windows, select the printer by clicking Select Printer or Printer in the printing
dialog box and try printing again.
In Mac OS X, open the dialog box of the printer driver, select the printer from the
list of Printer, and try printing again.
The print job is paused. (The
printer is in Sleep mode.)
In Windows, restart the print job as follows.
1. Select the printer icon in the Printers and Faxes (or Printers ) window.
2. Clear Pause Printing in the File menu to restart the print job.
In Mac OS X, restart the print job as follows.
1. Click Print
& Fax. (This is identified as Printer Setup Utility or Print Center
in other versions of Mac OS X.)
2. Select the printer, and then Resume Printer (or Start Jobs ) in the Printers
menu to restart the print job.
The printer does not respond even if print jobs are sent
Cause Corrective Action
The printer is offline. Press the Online button on the Control Panel to bring the printer on-
line.
You have printed when select Save in mail
box is selected in Output Method.
Print the job saved on the printer's hard disk.
(See "Printing Saved Jobs.") →P.572
Ink Filling.. is displayed
Cause Corrective Action
The printer was forced off during oper-
ation.
Wait until the system has been filled with ink. This process may take about
ten minutes.
Troubleshooting
> Printing does not start >
iPF815 The Data lamp on the Control Panel does not light up
12
863

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
