Canon imagePROGRAF iPF815 User Manual

Setting Item Description, Instructions
Output Method
Save: Box 01
Select the output method.
To print as usual, select Print. Selecting Print (Auto Del)
will print the job and then delete the data from the printer's
hard disk. Selecting Save: Box 01 will only save the print
job in the box, without printing it.
Save and Print Select On to print the job after it has been saved.
Save: Shared Box Select Off to print without saving jobs in the box shared
among multiple users.
Show Job Log Selecting Off prevents display of the log in Job Menu >
Job Log. Additionally, the log is not printed if you choose
Job Menu > Print Job Log. Note that because job logs
are not collected, the Status Monitor accounting functions
will not work correctly.
Information
Setting Item Description, Instructions
System Info Firmware Displays the printer firmware version.
Boot Displays the version of the boot ROM.
MIT Displays the version of the MIT database format.
s/n Displays the printer's serial number.
MAC Displays the MAC address of the printer.
IP Displays the printer's IP address.
Error Log ########-#### Displays the most recent error messages (up to two).
Main Menu Settings (During Printing)
Main menu
items during printing are described in the following tables.
For instructions on selecting or setting menu items, see "Main Menu Operations."
→P.705 .
For details on menu levels and values, see "Menu Structure." →P.709
Setting Item Description, Instructions
Menu Durng Prtng Head Cleaning Printhead cleaning options. (See "Cleaning the Print-
head.") →P.819
Choose Head Cleaning A if printing is faint, oddly col-
ored, or contains foreign substances.
Choose Head Cleaning B if no ink is printed at all, or if
printing is not improved by Head Cleaning A.
Fine Band Adj. Fine-tune the feed amount manually.
Information Displays the information about the printer and history of
print jobs. (See "Information.") →P.735
Printer Parts
> Control Panel >
Main Menu Settings (During Printing) iPF815
9
734

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
