Canon imagePROGRAF iPF815 User Manual

k.
▲ Button
Offline: Press this button to rewind rolls manually. (See "Feeding Roll Paper Manually.") →P.638
Menu mode: Press this button to display the previous menu item or setting value.
l.
▼ Button
Offline mode: Press this button to feed the roll manually in the direction of ejection, as needed.
(See "Feeding Roll
Paper Manually.")
→P.638
Menu mode: Press this button to display the next menu item or setting value.
m.
▶ Button
Menu mode: Press this button to display the menu one level lower.
n.
OK Button
In Menu mode, press this button to confirm or execute the selected item or setting. Also press this button if the Display
Screen indicates to press the OK button.
o.
Information
Button
Displays printer submenus. Press this button to display information about ink, paper, and so on. (See "Submenu Dis-
play.")
→P.735
You can also hold down this button for three seconds to clean the Printhead ( Head Cleaning A ).
p.
Power Button
Turns the printer on and off. (See "Turning the Printer On and Off.") →P.694
q.
Load/Eject Button
By pressing this button, you can check instructions on loading and removing paper. Instructions for loading paper are
shown
on the Display Screen if pressed when no paper is loaded, and instructions for removing paper are shown if
paper is loaded.
r.
Stop Button
Hold down for at least a second to cancel print jobs in progress or end the ink drying period.
Note
• In Sleep mode, you can press any button except the Power button to bring the printer online again.
Turning the Printer On and Off
Turning the printer on
1. Press the Power button to turn on the printer.
The printer will now start up.
After the Display Screen shows the Canon logo, "Starting up... Please wait." is displayed.
Printer Parts
> Control Panel >
Turning the Printer On and Off iPF815
9
694

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
