Canon imagePROGRAF iPF815 User Manual

Cannot Load Sheets
Cause Corrective Action
The paper source selection is incorrect. Press the Feeder Selection button to activate the Cut Sheet lamp.
Paper is not cut straight
Cause Corrective Action
The paper is bent or curled at the cut position. Straighten out any curling by the edges of the paper.
Paper rises by the ends of the cut position before it is cut. Reload the paper correctly.
Paper is not cut
Cause Corrective Action
In the printer driver, No or Print Cut Guideline
is specified in Auto Cut.
Specify Yes in Auto Cut in the printer driver.
In MAIN MENU, Eject or Manual is specified
in Cutting Mode.
Specify Automatic in Cutting Mode in MAIN MENU.
Rolls are not cut when you are using the Media
Take-up Unit.
Either execute Paper Cutting in the Control Panel or lift the Re-
lease Lever and cut the roll with scissors.
(See "Removing Printed Documents from the Media Take-up
Unit.") →P.761
The Media Take-up Unit Continues Rotating
Cause Corrective Action
There is a foreign object in the path of the Media Take-up Sensor (indicated
by a dotted line).
Remove the foreign object from the
Media Take-up Sensor path. Arrange
the Basket Cloth and Basket Rod so
they do not interfere with the Media
Take-up Sensor.
Troubleshooting
> Problems Regarding Paper >
iPF815 Cannot Load Sheets
12
861

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
