Canon imagePROGRAF iPF815 User Manual

Messages regarding printheads
Cannot adjust printhead. ................................................................................................................................. 909
Cannot adjust band. ........................................................................................................................................ 909
PHead needs cleaning. ................................................................................................................................... 910
Wrong printhead. ............................................................................................................................................. 910
Problem with Printhead ................................................................................................................................... 910
Printhead error ................................................................................................................................................ 910
No printhead .................................................................................................................................................... 910
Execute printhead cleaning. ............................................................................................................................ 911
Cannot adjust printhead.
Cause Corrective Action
The Printhead noz-
zles are clogged.
Execute Auto Head Adj. again, as follows.
1. Press the Online button to clear the error.
2. Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.") →P.817
3. Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.") →P.819
4. Execute Auto Head Adj. again.
(See "Automatic Straightening of Lines and Colors (Auto Head Adj.).") →P.668
The Printhead can-
not be aligned; high-
ly transparent film is
loaded.
Press the Online button to clear the error.
We recommend using a type of paper that you often use, other than film, for Printhead adjust-
ment.
(See "Automatic Straightening of Lines and Colors (Auto Head Adj.).") →P.668
The Printhead is in-
stalled crooked.
Straighten the Printhead as follows, and then execute Auto Head Adj. again.
1. Press the Online button to clear the error.
2. Use Head Inc. Adj. to adjust the angle of inclination of the Printhead.
(See "Adjusting Line Misalignment (Head Inc. Adj.).") →P.672
3. Execute Auto Head Adj. again.
(See "Automatic Straightening of Lines and Colors (Auto Head Adj.).") →P.668
Cannot adjust band.
Cause Corrective Action
The Printhead nozzles are clog-
ged.
Execute Auto Band Adj. again, as follows.
1. Press the Online button to clear the error.
2. Print a test pattern to check the nozzles.
(See "Checking for Nozzle Clogging.")
→P.817
3. Clean the Printhead if the nozzles are clogged.
(See "Cleaning the Printhead.")
→P.819
4. Execute Auto Band Adj. again.
(See "Auto Band Adjustment (Auto Band Adj.).") →P.677
Error Message
> Messages regarding printheads >
iPF815 Cannot adjust printhead.
13
909

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
