Canon imagePROGRAF iPF815 User Manual

Note
• Attach
the cap from the new Shaft Cleaner on the used one. Be sure to put the used Shaft Cleaner in
the small box before putting it in the larger box with the used Maintenance Cartridge for disposal.
8. Close the Top Cover.
The Carriage is moved, and the printer goes online.
Checking the Remaining Maintenance Cartridge Capacity
The Maintenance Cartridge absorbs excess ink from borderless printing, printhead cleaning, and other processes. You can
confirm the remaining capacity of the Maintenance Cartridge by checking the Maintenance Cartridge capacity shown on the
Display Screen.
Press the Information button to display the remaining capacity of the Maintenance Cartridge on the Display Screen.
If the Display Screen indicates to replace the Maintenance Cartridge, replace the Maintenance Cartridge. If a message is
displayed indicating to check the remaining capacity of the Maintenance Cartridge, or before tasks that deplete much of the
capacity such as head cleaning or preparations to move the printer, check the remaining Maintenance Cartridge capacity and
replace the Maintenance Cartridge as needed. (See "Replacing the Maintenance Cartridge.") →P.827
When to Replace the Maintenance Cartridge
Replace or prepare to replace the Maintenance Cartridge in the following situations.
Maintenance
> Maintenance Cartridge >
iPF815 Checking the Remaining Maintenance Cartridge Capacity
11
835

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
